Description
Assembly specs
- Crankset diameter: 24mm (Shimano)
- Frame width: 68 mm (Compatible with road bikes)
- Frame diameter: BSA
- For Threaded frames
This bottom bracket uses a regular BSA tool for its assambly and dissasambly.
Examples: Parktool BBT-69.3, Shimano TL-FC32 or similar: 44 mm diameter on the outer side and 42.7 mm diameter on the inside. 16 pins.
Weight: 102 grams
BSA Road Bottom Bracket or Shimano Characteristics
- Dual Cup Technology. Two aluminium cups that perfectly align bearings on both sides, creating a solid center joint that eliminates any noise or movements issues.
- This bottom bracket uses Chronium Steel Bearings (ABEC5 /P5 – 2RS).
- The cups of our bottom brackets are made from 7075 Aluminium, a high-strenght aerospace-grade aluminium on which we apply a T6 treatment. That makes the material harder and more durable, ensuring that our cups mantain top performance over time.
- Fully sealed. Axial seals on bearings and fully sealed on all surfaces.
- Lighter. The number of pins on this bottom bracket has been reduced to make it lighter.
Warranty
- Lifetime warranty for the cups.
- 3 year warranty for the bearings.
If you are unsure about the compatibility between your bike and this bottom bracket, please Whatsapp us 91692648
